Broadcast Receivers For Beginners

Let's say you have an application that depends on a steady internet connection. You want your applic a tion to get notified when the internet connection changes. How do you do that? A possible solution would be a service which always checks the internet connection. This implementation is bad for various reasons so we won't even consider it. The solution to this problem is a Broadcast Receiver and it will listen in on changes you tell it to. A broadcast receiver will always get notified of a broadcast, regardless of the status of your application. It doesn't matter if your application is currently running, in the background or not running at all.

Background

Broadcast receivers are components in your Android application that listen in on broadcast messages(or events) from different outlets:

From other applications
From the system itself
From your application

Meaning, that they are invoked when a certain action has occurred that they have been programmed to listen to (I.E., a broadcast).

A broadcast is simply a message wrapped inside of an Intent object. A broadcast can either be implicit or explicit.

An implicit broadcast is one that does not target your application specifically so it is not exclusive to your application. To register for one, you need to use an IntentFilter and declare it in your manifest. You need to do all of this because the Android operating system goes over all the declared intent filters in your manifest and sees if there is a match. Because of this behavior, implicit broadcasts do not have a target attribute. An example for an implicit broadcast would be an action of an incoming SMS message.
An explicit broadcast is one that is targeted specifically for your application on a component that is known in advance. This happens due to the target attribute that contains the application's package name or a component class name.

There are two ways to declare a receiver:

By declaring one in your AndroidManifest.xml file with the <receiver> tag (also called static)

AndroidManifest.xml

You will notice that the broadcast receiver declared above has a property of exported="true" . This attribute tells the receiver that it can receive broadcasts from outside the scope of the application.

2. Or dynamically by registering an instance with registerReceiver (what is known as context registered)

Implementation

To create your own broadcast receiver, you must first extend the BroadcastReceiver parent class and override the mandatory method, onReceive:

Putting it all together yields:

MyBroadcastReceiver.java

⚠️The onReceive method runs on the main thread, and because of this, its execution should be brief.

If a long process is executed, the system may kill the process after the method returns. To circumvent this, consider using goAsync or scheduling a job. You can read more about scheduling a job at the bottom of this article.

Dynamic Registration Example

To register a receiver with a context, you first need to instantiate an instance of your broadcast receiver:

Then, you can register it depending on the specific context you wish:

The first parameter for the IntentFilter is a string representing an action

Don't forget to unregister your broadcast receiver when you no longer need it

Broadcasting An Event

The point behind broadcasting messages from your application is to allow your application to respond to events as they happen inside of it. Think of a scenario where in one part of the code, the user performs a certain action and because of it, you want to execute some other logic you have in a different place.

There are three ways to send broadcasts:

The sendOrderedBroadcast method, makes sure to send broadcasts to only one receiver at a time. Each broadcast can in turn, pass along data to the one following it, or to stop the propagation of the broadcast to the receivers that follow
The sendBroadcast is similar to the method mentioned above, with one difference. All broadcast receivers receive the message and do not depend on one another
The LocalBroadcastManager.sendBroadcast method only sends broadcasts to receivers defined inside your application and does not exceed the scope of your application.

Example of sending a custom broadcast

Gotchas And Things To Pay Attention To

Do not send sensitive data through an implicit broadcast, because any application listening in for it, will receive it. You can prevent this by either specifying a package or attaching a permission to the broadcast
Don't start activities from a broadcast received as the user experience is lacking. Choose to display a notification instead.

The following bullet points refer to changes in broadcast receivers relevant for each Android OS version (starting from 7.0). For each version, certain limitations have taken places and behavior has changed as well. Keep these limitations in mind when thinking about using a broadcast receiver.

7.0 and Up (API level 24) - Two system broadcasts have been disabled, Action_New_Picture and Action_New_Video (but they were brought back in Android O for registered receivers)
8.0 and Up (API level 26) - Most implicit broadcasts need to be registered to dynamically and not statically (in your manifest). You can find the broadcasts that were whitelisted in this link.
9.0 and Up (API level 28) - Less information received on Wi-Fi system broadcast and Network_State_Changed_Action.

The changes in Android O are the ones you need to be the most aware of. The reason these changes were made was because it lead to performance issues, battery depletion and hurt user experience. This happened because many applications (even those not currently running) were listening in on a system wide change and when that change happened, chaos ensued. Imagine that every application registered to the action, came to life to check if it needed to do something because of the broadcast. Take into account something like the Wi-Fi state, which changes frequently, and you will begin to understand why these changes took place.

Alternatives to Broadcast Receivers

To make it easier to navigate all these restrictions, below is a breakdown of other components you can use in the absence of a broadcast receiver. Each one has a different responsibility and use case, so try to map out which one caters to your needs.

LocalBroadcastManager - As I mentioned above, this is valid only for broadcasts within your application
Scheduling A Job - A job can be run depending on a signal or trigger received, so you may find that the broadcast you were listening on can be replaced by a job. Furthermore, the JobScheduler, will guarantee your job will finish, but it will take into account various system factors(time and conditions)to determine when it should run. When creating a job, you will override a method called onStartJob . This method runs on the main thread, so make sure that it finishes its work in a limited amount of time. If you need to perform complex logic, consider starting a background task. Furthermore, the return value for this method is a boolean, where true denotes that certain actions are still being performed, and false means the job is done
